Axio bertrand

Begonnen von Adam Long, Juni 11, 2025, 10:25:03 VORMITTAG

Vorheriges Thema - Nächstes Thema

Adam Long

Apologies for the english!

A question for the Zeiss experts - was there ever a bertrand lens option for the Axioskop?

I know there was a slider for the Plan/Phot, and a telescope for the Skop.

I am slowly building an infinite tripod and have both Axioplan and Axioskop tripods. I would prefer to commit to the Skop for it's smaller footprint, but the bertand lens is my most used extra on my Universal.

Thanks.

Aljoscha

Hi Adam,

yes, there was. It is a slider like the ones for fluorescence filters that contained the Bertrand lens. It had 3 positions, bright field, polarization and Bertrand. A quite rare item.

Regards

Alexander

Adam Long

Many thanks Alexander. I will do some more research.

If I could find one, I am wondering if there would be any remaining advantages to the Axioplan. I suppose the rotating table can be centred. Is the light path bigger?


Aljoscha

Hi Adam,

The rotating table for Axioskop cannot be centered. This is an Axioplan only feature. All you can do is to mount it as centered as possible.

Regards

Alexander
